2.5KW Water Circulated Split Heat pump

Model		250L-300L
Power supply		220-240V~, 1Ph, 50Hz
Nominal tank volume	L	250-300
Heating capacity (Heat pump only)	kW	2.5
Heating Element	kW	2
Input (Heat pump only)	W	555
COP		4.5
STC (Zone 1 / 2 / 3 / 4 / 5)		25 / 25 / 30 / 32 / 31
Current (Heat pump only)	A	2.46
Max. input	W	2870
Max. current	A	13.1
Air flow	m3/h	750
Max.leaving water temperature (Heat pump only)	°C	60
Hot water yield	L/h	52
Available		About 2-3 peoples
Working ambient temperature (Heat pump only)		-7°C to 43°C
Sound pressure level	dB(A)	49
Max. operating water pressure	MPa	0.8
Water resistance		IP×4
Refrigerant type / Factory charged		R290 / 0.27kg
Throttling type		Electric expansion valve
Compressor Model		13.5CC
Type ×Quantity		Rotary ×1
Brand		GMCC
Fin material		Hydrophilic aluminum
Tube Material		Inner groove copper tube
Tube outside diameter	mm	Φ7
Double wall plate heat exchanger		SUS316
Motor type		BLDC
Speed	rmp	600-900
Fan type ×Quantity		Axial ×1
Water pump model		GPD25-4SN
Flow rater	m3/h	0.9
Inner tank material		Enamel
Rated inner tank pressure	MPa	0.8
Insulation		Polyurethane
Outer tank material		Galvanized steel
Inlet water pipe connection	mm	G3/4''
Outlet water pipe connection	mm	G3/4''
Unit dimension (ΦD×H)	mm	855330550
Packing dimension (L×W×H)	mm	750×745×2,210
Net / Gross weight	kg	40/53
